Smart Electronics RFID card reader module RC522 serial port reader 13.56mhz IC card RF module development board

Products > WIFI/GPS/GMS/Wireless RF Module > Smart Electronics RFID card reader module RC522 serial port reader 13.56mhz IC card RF module development board
    • 1
    • 2
    • 3
    • 4
    • 5

Smart Electronics RFID card reader module RC522 serial port reader 13.56mhz IC card RF module development board

RFID card reader module RC522 serial port reader 13.56mhz IC card RF module development board

Product model: RC522
Sleep current:<80uA
Peak current:<30mA
Working frequency: 13.56MHz
Card reading distance: 0-45mm
Interface: UART TTL
Baud rate: 115200
Data transmission rate: limited to 10Mbit/s
Environmental working temperature: -20-80 degrees Celsius
Storage temperature: -40-85 degrees Celsius
Humidity: Relative humidity 5% -95%
Protocol: Compliant with ISO14443A standard, supports S50, S70
shared：
RFID card reader module RC522 serial port reader 13.56mhz IC card RF module development board

Product Description

Product model: RC522 Sleep current:<80uA Peak current:<30mA Working frequency: 13.56MHz Card reading distance: 0-45mm Interface: UART TTL Baud rate: 115200 Data transmission rate: limited to 10Mbit/s Environmental working temperature: -20-80 degrees Celsius Storage temperature: -40-85 degrees Celsius Humidity: Relative humidity 5% -95% Protocol: Compliant with ISO14443A standard, supports S50, S70
