Raspberry Pi 4 generation Raspberry Pi 4B development board dual-band WIFI BLE 5.0 dual display output

Products > Raspberry Pi Series > Raspberry Pi 4 generation Raspberry Pi 4B development board dual-band WIFI BLE 5.0 dual display output

Raspberry Pi 4 generation Raspberry Pi 4B development board dual-band WIFI BLE 5.0 dual display output

Item Specification:

Broadcom BCM2711, Quad core Cortex-A72 (ARM v8) 64-bit SoC1.5GHz

1GB, 2GB or 4GB LPDDR4-2400 SDRAM (depending on model)
2.4 GHz and 5.0 GHz IEEE 802.11ac wireless, 5.0, BLE
Gigabit Ethernet
2 USB 3.0 ports; 2 USB 2.0 ports.
Raspberry Pi standard 40 pin GPIO header (fully backwards compatible with previous boards)
2 × micro-DMI ports (up to 4kp60 supported)
2-lane MIPI DSI display port
2-lane MIPI CSI camera port
4-pole stereo audio and composite video port
H.265 (4kp60 decode), H264 (1080p60 decode, 1080p30 encode)
OpenGL ES 3.0 graphics
Micro-SD card slot for loading operating system and data storage
5V DC via USB-C connector (minimum 3A*)
5V DC via GPIO header (minimum 3A*)
Power over Ethernet (PoE) enabled (requires separate PoE HAT)
Operating temperature: 0 – 50 degrees C ambient
shared:

Smart Electronics Raspberry Pi 4 generation Raspberry Pi 4B development board dual-band WIFI BLE 5.0 dual display output
Model Number
Raspberry Pi 4
Type
Development Board
Place of Origin
United Kingdom
Memory Capacity
1/2/4/8GB
Demo Board Type
ARM
SKU Options
01-Raspberry pie 4B 1G memory
02-Raspberry pie 4B 1G memory
03-Raspberry pie 4B 2G memory
04-Raspberry pie 4B 4G memory
05-Official DESKTOP KIT 4G
 06-A kit-1G memory
 07-A kit-2G memory
 08-A kit - 4G memory

Item Specification:

Broadcom BCM2711, Quad core Cortex-A72 (ARM v8) 64-bit SoC1.5GHz

1GB, 2GB or 4GB LPDDR4-2400 SDRAM (depending on model) 2.4 GHz and 5.0 GHz IEEE 802.11ac wireless, 5.0, BLE Gigabit Ethernet 2 USB 3.0 ports; 2 USB 2.0 ports. Raspberry Pi standard 40 pin GPIO header (fully backwards compatible with previous boards) 2 × micro-DMI ports (up to 4kp60 supported) 2-lane MIPI DSI display port 2-lane MIPI CSI camera port 4-pole stereo audio and composite video port H.265 (4kp60 decode), H264 (1080p60 decode, 1080p30 encode) OpenGL ES 3.0 graphics Micro-SD card slot for loading operating system and data storage 5V DC via USB-C connector (minimum 3A*) 5V DC via GPIO header (minimum 3A*) Power over Ethernet (PoE) enabled (requires separate PoE HAT) Operating temperature: 0 – 50 degrees C ambient
